Mechanical punching machine, also known as mechanical stamping machine. It uses the compressed air provided by the compressed air pump to enter the cylinder through the solenoid valve, drive the piston to the spindle to make the spindle move downward, and that creates momentum, and then the workpiece can be deformed in the die to achieve the purpose of processing.
Working Principle of Mechanical Punch Machine
Products or parts produced by punch or hydraulic machine tools for mechanical punching machines are called stamping parts. Basic requirements: stamping power, male die, mother die and raw materials of products (usually metal sheet or wire). The working principle of the punching machine is that the machine tool drives the opening and closing of the male die and the female die under the action of punching power, and the raw materials between them are cut, punched and stretched.
|J23-12T model mechanical punching machine technical parameters|
|Nominal force||120 KN|
|Nominal Stroke||2 mm|
|Slide Stroke||50 mm|
|Stroke times||140 times/min|
|Die height||130 mm|
|Die height adjustment||40 mm|
|Worktable Size||Front-back||220 mm|
|Shouk size||Φ30 mm|
|Workbench thickness||35 mm|
|Workbench plate hole size||Φ90 mm|
|Motor power||1.5 kw|
|Distance between two pillars of fuselage||170 mm|
|Overall dimension||Length||600 mm|
|Basic size||Front-back||500 mm|
|Depth of throat||130 mm|
|Distance from worktable to punch pin||220 mm|
LCL: We will use plastic film winding machine, and then put the machine into the wooden box to prevent damage in transportation.
FCL: If you buy a large number of machines, we will transport them in containers and fix each machine in the container.
◆ According to customers'needs, we will communicate with our engineers to recommend the most suitable model for you, and make a detailed quotation for your reference.
◆ If you want to visit our factory, we can meet you at the airport or at the station.
◆ We can arrange engineers to go to the customer's country for on-site installation and commissioning.
◆ For non-man-made damaged vulnerable parts, we can provide them free of charge.
◆ If you encounter any problems during the use of the machine, you can contact us at any time, and we will reply within 24 hours.
1. Are you the manufacture? Can we visit your factory?
◆ Of course, you can. We are manufacturer and we are located in Anhui,China. We have our own team for products design. Welcome to visit our factory and check our machine qualtiy, any question will be solved on time.
2.What's your main product? What is your main foreign market?
◆ Our main products are press brake, shears machines, press, cutting machine, locking machine , auto duct line and related products.Our main foreign markets are Asia, North America, Europe, and Africa.
3. What are the advantages of your machines? And how can I believe the quality of your product?
◆ The main configuration is import high quality products, and professional product quality inspection team ensures machine in top-quality, precision and life. For example, Germany Bosch-Rexroth Valve group,Germany Siemens Main Motor,Schneider Electrics system and so on. Once tested as qualified, our machine would be sent out. So The quality of our product is stable and reliable.
4. Are you able to update the production process Information in time after placing our order?
◆ After confirming your order ,we would keep you updated of production details of emails and photos.
5. Can we be your agent?
◆ Yes,we are looking for global agent, and we will help agent improve the market ,and supply all the service like machine
technical problem or other after-sales problem, meanwhile ,you can get big discount and commission.
6. Payment terms?
◆ T/T, L/C, Western Union, Paypal, Alibaba Secure Payment ect.
7. Are you provide product metal parts and provide us technical guidance?
◆ Wearing parts, Disassembly tool(free) are what we could provide.And we can give you technical guidance.Our technical staff can go abroad to provide you with professional technical guidance.
8. How long is your warranty?
◆ 2 years free warranty, life-long maintenance.
9. Do you accept customer Logo and customized ?
◆ We accept kinds of customized , including logo and machine .
- CNC or Not: Normal
- Condition: New
- Machine Type: Punching Machine
- Slide Stroke (mm): 50 mm
- Power Source: Mechanical
- Voltage: 220V/380V/Customized
- Dimension(L*W*H): 600x530x1500 mm
- Motor Power (kW): 1.5
- Model Number: J23-12T
- Weight (T): 0.38
- Key Selling Points: Competitive Price
- Warranty: 2 years
- Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
- Showroom Location: None
- Marketing Type: Other
- Machinery Test Report: Provided
- Video outgoing-inspection: Provided
- Warranty of core components: 2 years
- Core Components: Bearing, Pump, Gear, Motor, Gearbox, PLC, Pressure vessel, Engine
- Nominal Stroke: 2mm
- Slide Stroke: 50mm
- Stroke times: 140 times/minute
- Depth of throat: 130mm
- Motor Power: 1.5kw
- Workbench thickness: 35mm
- Die height: 130mm
- Die-filling diesetheightadjustment: 40mm
- Nominal Force (kN): 120 kN
- Certification: CE
