Single Column 30 Ton Mini Hydraulic Press Machine

This hydraulic press machine could be used in calibration process of shaft parts ,bearing and other similar parts. also could press-fit the shaft and sleeve parts , and this hydraulic press could be used the simple strip shape element stretch, moulding, blanking , coining and so on processing .

Specification		Unit	Y41-40	Y41-63	Y41-100	Y41-160	Y41-200	Y41-250	Y41-315
Nominal force		KN	400	630	1000	1600	2000	2500	3150
Throat depth		mm	320	320	340	325	350	400	400
Max height		mm	700	700	900	1000	1000	1000	1100
Slide stroke		mm	500	500	500	500	600	600	600
Table area	L-R	mm	580	580	750	750	800	850	900
	F-B	mm	560	560	630	630	650	700	750
Speed of slide	Descent	mm/s	48	38	38	20	25	60	65
	Pressing	mm/s	12	10	10	8	4	3.7	4
	Return	mm/s	135	95	118	100	65	80	65
Overall dimension	L-R	mm	900	930	1200	1200	1300	1200	1500
	F-B	mm	1500	1600	1600	1700	1900	2000	2100
	H	mm	2400	2600	2900	3100	3400	3500	3750
Table hight above floor		mm	650	650	700	650	700	700	600
Main motor power		KW	5.5	7.5	11	15	15	15	22

OPTIONAL INSTALLATION

1. Blanking damping installation
2. screen safety protection device
3. Touch display screen in industrial
4. Rapid clamp mold installation
5. Floating guideway and rolling bracket for changing mold
6. Slider locking installation
7. Removable table
8. Oil cooling installation
9. Ramming installtion

Performance

1.Single column adjusting press-assembly hydraulic press is widely used in adjusting ,metal beniding,pressing and so on.
2.This machine can be controlled by foot pedal switch,pressure is adjustable and stroke can be controlled, easily and realiability.

OUR SERIVE

Pre-sales.

* Project design, performance introduction, technical agreement, contract signing, packaging * Inquiry and consulting support.
* Sample testing support.

In-sales.

* We will provide you with the latest progress in the product assembly, packaging and transportation.

After-sales

* We will provide free accessories for the damage to non - human parts.
* Training how to install the machine, training how to use the machine with video and so on
* And our technical staff can go abroad to provide technical guidance.

FAQ

1. Are you the manufacture?Can we visit your factory?

We are manufacturer and we are located in Anhui, China. And we have our own design team for products design. And welcome you visit our factory and check our machine qualtiy on spot,any question will be solved on spot at first time.

2. What's your main product and what is your main foreign market?

Our main products are press brake, shears machine, press, cutting machine, locking machine, auto duct line and related products. Our main foreign market are Asia, North America, Europe, Africa.

3. What are the advantages of your machines?And how can i believe the quality of your product?

The main configuration is to import quality products, and Professional product quality inspection team ensure machine in top-quality, precision and life. For example, Germany Bosch-Rexroth Valve group, Germany Siemens Main Motor, Schneider Electrics system and so on. Once tested as qualified .our machine would be sent out. So The quality of our product is stable and reliable.

4. And are you able to update the production process Information in time after placing our order?

After confirming your order, we would keep you updated of production details of emails and photos.

5. Can we be your agent?

Yes,we are looking for Global agent we will help agent improve the market ,and supply all the service like machine technical problem or other after-sales problem, meanwhile ,you can get big discount and commission.

6. Payment terms?

T/T, L/C, Western Union, Paypal, Alibaba Secure Payment ect.

7. Are you provide product metal parts and provide us technical guidance?

Wearing parts, Disassembly tool(free) are what we could provide.And we can give you technical guidance.Our technical staff can go abroad to provide you with technical guidance.

8. How long is your warranty?

13 months free warranty, life-long maintenance.

9. Do you accept customer Logo and customized ?

We accept kinds of customized ,including logo and machine .

Details

• Slide Stroke (mm): 500
• Machine Type: Single Column Hydraulic Press
• Ejector Force (kN): 400
• Return Force (kN): 400 kN
• System: Normal
• Condition: New
• Year: 2021
• Voltage: 220v/380v or customized
• Dimension(L*W*H): 900mmx1500mmx2400mm
• Weight (T): 2.5 T
• Model Number: Y41-30
• Motor Power (kw): 7.5 kw
• Key Selling Points: Competitive Price
• Warranty: 2 years
• Applicable Industries: Farms, Food & Beverage Shops, Building Material Shops, Garment Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Food Shop, Advertising Company, Restaurant, Hotels, Printing Shops, Retail, Home Use, Energy & Mining, Construction works , Other
• Showroom Location: None
• Marketing Type: Ordinary Product
• Machinery Test Report: Provided
• Video outgoing-inspection: Provided
• Warranty of core components: 2 years
• Core Components: Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox
• Type: CNC
• Power Source: Hydraulic
• Product name: Hydraulic Press
• Color: Customizable
• Slide stroke: 500mm
• Application: Metal Forming
• Speed of slide: 48/12/135 descent/pressing/return
• Overall dimension: 900x1500x2400mm
• After-sales Service Provided: Engineers available to service machinery overseas
