Hydraulic Pendulum Cnc Swing Beam Sheet Metal Plate Shearing Machine

Products Description

Max. Cutting Thickness (mm):6 mm
Blade Length (mm):3200 mm
Throat Depth (mm):150 mm
Power (kW):7.5 kW
Weight (KG):8800 KG
Max. Cutting Width (mm):3200 mm
Voltage:according to consumers' request
Electric parts:Siemens & Schneider
Warranty2 years
Key Selling Points:Multifunctional
ApplicationMild carbon stainless steel plate or iron sheet
Weightas per machine specification

Hydraulic Pendulum Cnc Swing Beam Sheet Metal Plate Shearing Machine
Hydraulic Pendulum Cnc Swing Beam Sheet Metal Plate Shearing Machine

Why Choose Us?

For choosing proper/suitable Busbar Machine, we need to consider below items,

#1. Budget Affordable, Multi-Function,small workshop and medium-sized companies can afford it

#2. Capacity of machine

Based moldel of RAYMAX Busbar Machine
RAYMAX -30-3NC: 12mm x 160mm ( Thickness x Width )
RAYMAX -50-3NC: 16mm x 250mm ( Thickness x Width )
RAYMAX -80-3NC: 20mm x 300mm ( Thickness x Width )

#3. Accuracy of busbar machine

#4. Speed of production

#5. Facility of busbar machine

Bending,Punching and Cutting units in one machine ( 3 in 1 )
Three units can do work at the same time,no bother each other
SIEMENS CNC Control system,Touching operate interface,automated operation

#6. History of Busbar Machine manufacturer at service after sales

As the professor busbar machine manufacturer,we have more than ten years working experience. And,we have the complete production line,provide good service and reduce maintenance costs. Our machine always get the good response from our customers in the world market.
Hydraulic Pendulum Cnc Swing Beam Sheet Metal Plate Shearing Machine

In general, Busbar Machine has 3 main functions of bending, cutting, and punching.

But as a professional Busbar machine manufacturer, RAYMAX expectation extend to several more items. At busbar bending station accuracy of final bend is too much important. regarding to the spring back principle, busbars open after Bending function according to the purity of copper, size of busbar and degree of bend so it is very important that bender has spring back compensations system and has repeatability for same degree of bends. in addition at production lines some time we need special bends which is not possible to do with normal bending head. Two closed bends, edge bend and twist bend are inquiries that possible with some special Busbar bending machines.

At punching section ability of punching for circle, Oval and rectangle holes are important.Central laser pointer and professional X & Y guides to find position of hole is critical point for save setting time. At cutter station edge of final cutting part is important for having 90 ‘edge without any damage scrap is necessary. If busbar cutting machine eliminate scrap it damage to edge of bus bar especially for size more than 5mm likeness and result is not acceptable. At the end layout of stations for be user friendly machine is significant. Three operator should work with professional busbar machine without disturbance to each other and have serrate space.


Q1. What is your payment terms:

A: 30% TT as deposit, balance be paid when goods are ready for loading before shipment.

Q2. What is your power supply?

A: Our power supply is 380V,but we will adjust according to your countries power supply. No problem.

Q3. What is your Min order quantity?

A: One set. Our customers can be end-users, retailers, and wholesalers.

Q4. If I buy your CNC busbar processing machine, will you offer me PLC backup?

A:Yes, we will.Our standard configuration is Schneider's PLC.

Q5. Are all the Labels and instructions of the machine in our language ?

A: Yes, our standard configuration is English, we can customize your national language for you according to your requirements.


  • Max. Cutting Width (mm): 3200
  • Max. Cutting Thickness (mm): 6 mm
  • Automatic Level: /
  • Blade Length (mm): 3200 mm
  • Throat Depth (mm): 150 mm
  • Condition: New
  • Brand Name: RAYMAX
  • Power (kW): 7.5 kW
  • Weight (KG): 8800 KG
  • Place of Origin:  China
  • Voltage: 380V, according to consumers' request
  • Year: 2021
  • Warranty: 2 years, 2 years
  • Key Selling Points: /
  • Applicable Industries: Other
  • Showroom Location: None
  • Marketing Type: Ordinary Product
  • Machinery Test Report: Provided
  • Video outgoing-inspection: Provided
  • Warranty of core components: 2 years
  • Key Selling Points: Multifunctional
  • Name: CNC Shearing Machine
  • Certification: CE, CE,ISO
  • Weight (KG): 8800 KG
  • Power (kW): 7.5 kW
  • Packing: Wooden case
  • After-sales Service Provided: Online support, Video technical support
  • After Warranty Service: Video technical support, Online support
