250 Tons Safe Cnc Hydraulic Press Brake For Steel Sheet Metal Bending

Main Configuration

1. Full EU streamlined design, heat treatment rack,high rigidity worktable.

2. Estun NC controller E21/DA41for Y axis and X axis control.

3. Working-piece counting function.

4. Bending retraction function

5. Backgauge with ball screw and Manual R axis

6. Optional V axis for compensation function.

7. light curtain for safty , optional DSP laser protection.

8. CE certificate and ISO9001*2008
250 Tons Safe Cnc Hydraulic Press Brake For Steel Sheet Metal Bending

Stanard configuration

250 Tons Safe Cnc Hydraulic Press Brake For Steel Sheet Metal Bending

Estun E21 control (Y, X axis)

* Backgauge control

* Control the common motor or inverter

* lntelligent positioning

* Holding pressure unloading time setting

* Workpiece counting

* 40 programs stored, 25 steps per program

* Unilateral positioning

* Concession function

* One-key backup / restore

* mm / inch

* Chinese / English
250 Tons Safe Cnc Hydraulic Press Brake For Steel Sheet Metal Bending

Product Paramenters

Bending Capability80/3200100/3200100/4000125/3200125/4000160/3200160/4000
Nominal Force(KN)800100010001250125016001600
Worktable Length(mm)3200320040003200400032004000
Column Distance(mm)2490249030002490300024903000
Throat Depth(mm)250320320320320320320
Ram Stroke(mm)120120120120120180180
Main Motor Power(KW)
Bending Capability160/6000200/3200200/4000200/6000250/3200250/4000250/6000
Nominal Force(KN)1600200020002000250025002500
Worktable Length(mm)6000320040006000320040006000
Column Distance(mm)4100249030004600250030004600
Throat Depth(mm)320320320320350350350
Ram Stroke(mm)200200200200250250200
Main Motor Power(KW)11111115151515
Bending Capability300/3200300/4000300/6000400/4000400/5000400/6000500/4000
Nominal Force(KN)3000300030004000400040005000
Worktable Length(mm)3200400060004000500060004000
Column Distance(mm)2500300046003100360046003100
Throat Depth(mm)350350350350350350350
Ram Stroke(mm)250250250250250250250
Main Motor Power(KW)18.518.518.522223030
Bending Capability500/6000500/8000600/6000600/8000800/6000800/80001000/6000
Nominal Force(KN)50005000600060008000800010000
Worktable Length(mm)6000800060008000600080006000
Column Distance(mm)4600610046006100460061004600
Throat Depth(mm)350350400400400400500
Ram Stroke(mm)250300300300300300400
Main Motor Power(KW)30303745455555


  • Slider Stroke (mm): 200 mm
  • Automatic Level: Fully Automatic
  • Throat Depth (mm): 400 mm
  • Machine Type: Torsion Bar, Press Brake
  • Length of Working Table (mm): 4000 mm
  • Width of Working Table (mm): 120 mm
  • Condition: New
  • Material / Metal Processed: Brass / Copper, Stainless Steel, ALLOY, Carbon steel, Aluminum
  • Automation: Automatic
  • Extra Services: Machining
  • Weight (KG): 16500
  • Motor Power (kw): 15 kw
  • Key Selling Points: Automatic
  • Warranty: 2 years
  • Applicable Industries: Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
  • Showroom Location: None
  • Marketing Type: New Product 2020
  • Machinery Test Report: Provided
  • Video outgoing-inspection: Provided
  • Warranty of core components: 1 Year
  • Core Components: Bearing, Motor, Pump, Gear, PLC
  • Raw Material: Sheet / Plate Rolling
  • Model Number: WC67Y-250/4000
  • Open Height: 525mm
  • Nominal Pressure (kN): 2500 kN
  • Certification: ce
