1. The Frame is entirely welded with steel plates, and treated to relive stress by tempering.
2. Hydraulic drive, return of knife beam is smooth and prompt by accumulator or nitrogen cylinder.
3. It adopts three point supporting type rolling guide way to raise shearing precision.
4. Rectangle knife which has four blades has a lasting life.
5. The portable and prompt adjustment of the blades gap and the value of gap are indicated by digital, convenient and fast.
6. Equipped with lighting alignment, so as to align when shearing, the stroke of knife beam can be adjusted in stepless model.
7. Protection fence to ensure to operation safety.
8. The display devices of the back-gauge value and the shearing times, displays on the front of the machine.
9. The shearing angle can be adjusted.
E21S controller from Estun
1. Backguage and block control
2. Intelligent positioning 3.Program memory of up to 40 Programs up to 25 steps per program
4. One side position
5. Retract function
Except for E21s ,you can have more choice like E210s,E200s ,DA310 ,DA360 and ect
|Model||Shearing Thickness (mm)||Shearing Width (mm)||Strokes（ times/min）||Back gauge Range (mm)|
Warranty & After-sales Service
1. Our guarantee time is 5 years from B/L date. If any component is damaged during guarantee time, we can deliver the component to the customer by courier without any extra charge .
2. Our factory provide oversea engineer service training freely. The customer provide the double trip tickets, engineer salary , and accommodation for our engineer. The customer also can send the engineer to our factory for learning .
3. Our factory provide the service for the customer forever, if the customer need operation help, can contact us by wechat, Skype, Email , whatsapp and Telephone at any time, we provide 24 hours on-line service.
- Place of Origin: Anhui
- Brand Name: RAYMAX
- Condition: New
- Type: shearing machine
- Video outgoing-inspection: Provided
- Machinery Test Report: Provided
- Marketing Type: New Product 2020
- Warranty of core components: 1 Year
- Core Components: PLC, Engine, Motor, Pump
- Voltage: customized
- Rated Power: 5.5 KW
- Dimension(L*W*H): 3840*1710*1650
- Year: 2020
- Warranty: 3 years
- Key Selling Points: Competitive Price
- Applicable Industries: Building Material Shops, Machinery Repair Shops, Construction works , Advertising Company, Other
- Showroom Location: Kazakhstan, Ukraine, Uzbekistan, None
- model: QC11K-6x3200
- Cutting material: carbon steel, mild steel ,stainless steel
- Cutting Thickness: 6 mm
- Cutting Length: 3200mm
- Cutting Angle: 1.30\"
- Material Strength: ≤450
- Backgauge Range: 20-600 mm
- Travel Times: 12 Times/Min
- Power: 7.5KW
- Dimension: 3650x1750x1980
- After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service
- Local Service Location: None
- Weight: 5800
- Certification: CE
