Industry Laser Equipment 1000w Cnc Fiber Laser Cutting Machine For Steel Metal Sheet

Product Description

Industry Laser Equipment 1000w Cnc Fiber Laser Cutting Machine For Steel Metal Sheet

1. The double ball screw closedloop system and imported open CNC system enable high processing accuracy and high working efficiency during high speed cutting.

2. Standard collocation of 500W fiber laser generator and optional 400W-2000W fiber laser generator ensures low operation and maintenance cost.

3. Open structure is easy and convenient for material loading and unloading.

4. Aiming at high speed cutting, we design and manufacture strengthened welded machine body after 2 times of aging process which ensures long-term accuracy and stability of performance.

5. Standard collocation of dual-pressure gas control system of 3 gas sources (high pressure air, nitrogen, oxygen) meets the processing requirement of all kinds of materials.

6. Easy operation and low cost.

7. Optimized optical lens, specially designed nozzle and sensor technology realize smoother and more stable cutting.
Industry Laser Equipment 1000w Cnc Fiber Laser Cutting Machine For Steel Metal Sheet

CNC Fiber Laser Cutter Technical Parameters
Machine modelsDW1325 with 1000W Raycus
Control system & Nesting SoftwareCypCut control system
Cooling SystemWater Chiller
Lubrication SystemAutomatic Lubrication system
Electrical ComponentsSMC,Schneider
Assist Gas Choosing Control3 types of gases can be used
Repeat Position Accuracy±0.03mm
Position Accuracy±0.05mm
Min. Kerf0.1~0.05mm (depends on material thickness)
Max. Processing speed64m/min
Power Supply RequirementAC 380V ± 5% 50/60Hz 3Phase
500W: 2mm stainless steel, 6mm carbon steel.750W: 4mm stainless steel, 8mm carbon steel
1000W:5mm stainless steel, 10mm carbon steel1500W:6mm stainless steel, 12mm carbon steel
2000W:8mm stainless steel, 15mm carbon steel3000W:10mm stainless steel, 20mm carbon steel
4000W:12mm stainless steel, 22mm carbon steel

Industry Laser Equipment 1000w Cnc Fiber Laser Cutting Machine For Steel Metal Sheet

Details

  • Application: LASER CUTTING, Laser Cutting
  • Applicable Material: Metal
  • Condition: New
  • Laser Type: Fiber Laser
  • Cutting Area: 1500*3000mm
  • Cutting Speed: 80m/min
  • Graphic Format Supported: AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT, laser fiber cutting machine
  • Cutting Thickness: Depend on material
  • CNC or Not: Yes
  • Cooling Mode: WATER COOLING
  • Control Software: Cypcut
  • Warranty: 3 years, 3 years
  • Certification: CCC, ce, laser fiber cutting machine
  • After-sales Service Provided: Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Engineers available to service machinery overseas
  • Product name: Fiber Laser Metal Cutting Machine
  • Working area: 1300*2500mm
  • Laser power: Raycus 500w
  • Working table: Sawtooth work table
  • Control system: PC control with Cypcut
  • Drive system: Japan servo motor and drivers
