Wc67k-80t/2500 Hydraulic Press Brake Machine Metal Sheet Bending Machine

Machine Features

1. The frame is steel structure, left and right vertical plate, table and pressure plate welded into a unitary structure, after welding to eliminate internal stress by tempering, exceptional rigidity, high stability.

2. Important parts of the frame, sliders, etc. are used ANSYS finite element analysis software to ensure machine reliability.

3. Hydraulic drive, cylinder on both end of machine, disposed on the slider to drive it work directly.

4. Torsion axis synchronization for slide synchronous mechanism.

5. Adopt a mechanical stopper mechanism, stable and reliable.

6. Back Gauge size and slide stroke controlled by CNC system, back gauge with high precision ball screw, stable operation and precise positioning.

7. The controller system adopts frequency conversion control technology, with multi-step programming function, simple and easy to operate.

8. Inclined wedge deflection on the compensation mechanism, in order to guarantee access to high bending accuracy

9. Safety barrier device all around the machinery, electrical cabinets equipped with Open door cut-off function, emergency stop button around front and back, protective cover foot switch to ensure safe working.

E21 controller system (Standard NCcontroller system )

1）backgauge and block control

2）control for general AC motor ,frequency inverter

3）Intelligent positioning

4）Stock counter

5）Program memory of up to 40 programs & up to 25 steps per program

6）One side positioning

7）Retract function

8）One key back /restore of programs

9）Mm/inch / Chinese /English

Machine Parameters

Main Parameters
Model	Bending Force	Bending Length	Upright Distance	Throat Depth	Stroke	Opening Height	Overall Dimensions
	Kn	mm	mm	mm	mm	mm	L×W×H mm
WC67K/E-30t/1600	300	1600	1300	200	80	220	1650*1200*1700
WC67K/E-30t/2000	300	2000	1300	200	80	220	2000*1150*1700
WC67K/E-40t/2500	400	2500	2030	250	100	340	2500*1200*1900
WC67K/E-63t/2500	630	2500	2050	250	120	340	2500*1600*2200
WC67K/E-63t/3200	630	3200	2510	250	120	340	3200*1600*2200
WC67K/E-80t/2500	800	2500	2050	250	120	350	2500*1700*2200
WC67K/E-80t/3200	800	3200	2510	250	120	350	3200*1700*2200
WC67K/E-100t/2500	1000	2500	2050	320	120	380	2500*1500*2200
WC67K/E-100t/3200	1000	3200	2510	320	120	380	3200*1800*2500
WC67K/E-100t/4000	1000	4000	3100	320	120	380	4000*1800*2500
WC67K/E-125t/3200	1250	3200	2510	320	120	380	3200*1900*2600
WC67K/E-125t/4000	1250	4000	3100	320	120	380	4000*1435*2600
WC67K/E-160t/2500	1600	2500	2050	320	200	450	2500*1900*2700
WC67K/E-160t/3200	1600	3200	2510	320	200	450	3200*2000*2800
WC67K/E-160t/4000	1600	4000	3040	320	200	450	4000*2000*2800
WC67K/E-160t/5000	1600	5000	3800	320	200	450	5000*1900*3100
WC67K/E-160t/6000	1600	6000	4600	320	200	450	6000*1900*3300
WC67K/E-200T/3200	2000	3200	2600	320	250	540	3200*1820*3300
WC67K/E-200T/4000	2000	4000	3300	320	250	540	4000*2000*2850
WC67K/E-200T/5000	2000	5000	3800	320	250	540	5000*1950*3000
WC67K/E-200T/6000	2000	6000	4600	320	250	540	6000*1950*3300
WC67K/E-250T/3200	2500	3200	2600	400	250	580	3300*2000*3200
WC67K/E-250T/4000	2500	4000	3300	400	250	580	4000*2000*3400
WC67K/E-250T/5000	2500	5000	3800	400	250	580	5000*2000*3500
WC67K/E-250T/6000	2500	6000	4600	400	250	580	6000*2000*3600
WC67K/E-300T/3200	3000	3200	2600	400	250	580	3200*2100*3300

Details

• Slider Stroke (mm): 100 mm
• Automatic Level: Semi-automatic
• Throat Depth (mm): 250 mm
• Machine Type: Torsion Bar
• Length of Working Table (mm): 2500
• Width of Working Table (mm): 1450 mm
• Dimension: 2550*1450*2300, 2550*1450*2300 mm
• Condition: New
• Place of Origin: Anhui
• Material / Metal Processed: Brass / Copper, Stainless Steel, ALLOY, Carbon steel, Aluminum
• Automation: Automatic
• Extra Services: round bending
• Year: 2020
• Weight (KG): 4300
• Motor Power (kw): 7.5 kw
• Key Selling Points: Competitive Price
• Warranty: 3 years
• Applicable Industries: Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Retail, Construction works , Advertising Company, Other
• Showroom Location: Uzbekistan, Australia
• Marketing Type: New Product 2020
• Machinery Test Report: Provided
• Video outgoing-inspection: Provided
• Warranty of core components: 1 Year
• Core Components: Motor, Pump
• model: WC67K-80T/2500
• Cutting material: aluminum sheet ,mild steel ,carbon steel,stainless steel
• Bending thickness: MS 4mm / SS 2 mm
• Bending Length: 2500 mm
• Nominal pressure: 800KN
• Poles distance: 2500mm
• Slider travel: 100 mm
• Max open: 340 mm
• Power: 7.5 KW
• Certification: CE
• After-sales Service Provided: Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support
• After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service
