Plate shearing machine CNC hydraulic pendulum numerical control shearing machine plate shears easy to operate
1. Hydraulic control system by BOSCH-REXROTH Germany or FIRST America.
2. Oil seals by Japanese, NOK.
3. Overload & overflow protection to ensure there is no leakage and protect hydraulic system, and the oil level can be read
Servo motorized back gauge:
1. CNC Back gauge system with X axis by AC servo motor driven ball screw shafts and on linear bearings
2. Back gauge has well enough mechanical strength and rigidity with tank-type gauge structure.
3. High-precision ball screw and linear guide-way. Particular finger-stop design, enlarge the range of back gauge.
Electrical parts and protection device:
1. Schneider or Siemens Low-voltage apparatus. In accordance with international standards, reliable safety, long life,good
anti-interference ability, a radiation unit is fitted in electrical cabinet.
2. Protective fence and the safety interlock to ensure the operation safety. Have a movable single-hand pedal switch,easy to operate.
3. Light screen protection or Laser protection are optional.
|Type||Cutting length (mm)||cutting capacity mild steel 450N/mm²||cutting capacity stainless steel 700N/mm²||Cutting angle(°)||Throat Depth（mm)||Back gauge travel(mm)||Motor power (kw)||Overall Diamentions LxWxH(mm)|
Q. How to confirm the Machine Model?
A: You can tell us the material, max thickness and width of your plate. We will recommend the suitable model to you .
Q. How can I get a quotation?
A: Pls tell us the machine you need, including quantity, raw materials and other requirements.
Q. What is the payment term?
A: T/T (30% advance payment, and 70% balance paid one week before shipment) L/C (100% L/C at sight), this should be negotiated first.
Q. Will you show me how to install the machine?
A: Certainly, we will enclose the production specification with the machine, and we could provide the video online to you, and our engineers are available to service machinery overseas.
Q. After I buy the machine, what will you do if I don't know some of the function?
A: We will show you how to use the machine perfectly. Technical support and the video is available.
Q. What can I do if the machine troubled after I buy it?
A: We provide completely after sales service, and our engineers are available to service machinery overseas. ",
- Place of Origin: Anhui, China
- Brand Name: RAYMAX
- Condition: New
- Type: Shearing Machines
- Video outgoing-inspection: Provided
- Machinery Test Report: Provided
- Marketing Type: Ordinary Product
- Warranty of core components: 5 years
- Core Components: Engine, Motor, Pump
- Voltage: User Defined
- Rated Power: 5.5
- Dimension(L*W*H): 3840x1610x1620mm
- Warranty: 5 years
- Key Selling Points: Easy to Operate
- Applicable Industries: Manufacturing Plant
- Showroom Location: Germany
- Weight (KG): 9900 KG, 5900 KG
- Product name: Metal Steel Cutting Machine
- Control system: E21S/Estun E200/Delem DAC310s/DAC360S
- Usage: Shearing Metal Sheet
- Cutting material: Metal .Alloy Metal .Aluminum
- Backgauge Travel (mm): 20 - 600 mm
- Shearing Angle: 1°30'
- Max. Cutting Thickness (mm): 8 mm
- Throat Depth (mm): 250 mm
- Blade Length (mm): 1540 mm
